Machine Vision-NovaSense

Products

PN	Resolution 1.3MP 2.3MP 2.5MP 4MP 12MP 25MP 39MP 4K line array	Optical Format 1/2'' 1/2.6'' 1.5'' 1'' 1.1'' 1.2'' 2''	Pixel Size 4.8µm 3.0µm 9.9µm 5.5µm 5.94µm 2.7µm 7.0µm	Shutter Type GLOBAL ROLLING	HDR No Yes	Pixel Array 12801024 19281208 19361280 20482048 41283072 51205120 76805120 40964	Max Frame Rate 210fps 120fps 120/60fps 180fps 100fps 160fps 40kHz	CRA 0° 15°	Interface LVDS MIPI LVDS MIPI DVP	Package CLCC48 CSP CLCC110 CLCC92 CLCC
NV013G	1.3MP	1/2''	4.8µm	GLOBAL	No	1280*1024	210fps	0°	LVDS	CLCC48
NV02G	2.3MP	1/2.6''	3.0µm	GLOBAL	No	1928*1208	120fps	15°	MIPI LVDS	CSP
NV02R	2.5MP	1.5''	9.9µm	ROLLING	Yes	1936*1280	120/60fps	0°	MIPI DVP	CLCC110
NV04G	4MP	1''	5.5µm	GLOBAL	No	2048*2048	180fps	0°	LVDS	CLCC92
NV04R	4MP	1.1''	5.94µm	ROLLING	Yes	2048*2048	100fps	0°	LVDS	CLCC
NV12G	12MP	1.1''	2.7µm	GLOBAL	No	4128*3072	160fps	0°	LVDS	CLCC
NV25G	25MP	1.2''	2.7µm	GLOBAL	No	5120*5120	100fps	0°	LVDS	CLCC
NV39G	39MP	1.5''	2.7µm	GLOBAL	No	7680*5120	100fps	0°	LVDS	CLCC
NV4KL	4K line array	2''	7.0µm	GLOBAL	No	4096*4	40kHz	0°	LVDS	CLCC110
